Inground car lift L5800B

Technical Parameters

Lifting capacity: 5000kg

Max. Lifting height: 1750mm

Entire Lifting (Dropping)Time: 40-60sec

Load sharing: max. 6:4 in or against drive-on direction

AC220/380V/50 Hz；AC230/400V/50 Hz

Supply voltage: AC220/380V/50Hz; AC230/400V/50Hz

Power: 3 Kw

The pressure of the air source: 0.6-0.8MPa

Main unit length: 2690mm

Main unit width: 415mm

Main unit height: 2514mm

Post Diameter:195mm

Post thickness:13mm

Sound level (measured at control console): ≤75 dBA

N.W.：1865kg
