Inground car lift L5800A

Technical Parameters:

Lifting capacity: 5000kg

Max. Lifting height: 1850mm

Entire Lifting (Dropping)Time: 40-60sec

Load sharing: max. 6:4 in or against drive-on direction

Supply voltage: AC380V50Hz;

Power: 3 Kw

The pressure of the air source: 0.6-0.8MPa

Main unit length: 2690mm

Main unit width: 415mm

Main unit height: 2514mm

Post Diameter:195mm

Post thickness:13mm

oil tank capacity :12L

Sound level (measured at control console): ≤75 dBA
