Movable scissor battery lifting platform E-70

· Driven by electric hydraulic double cylinders, strong power and stable lifting.
· Scissor body structure, stable lifting.
· Equipped with a four-way sliding lifting platform to ensure accurate alignment of the battery installation.
· The lifting platform is equipped with fastening devices to ensure the safety and stability of the lifting platform under operating conditions.
· Equipped with four independent brake casters, easy to move, safe and stable operation.
· Equipped with wired remote control handle, easy to control.
· Optional DC12V and AC220V power units, easy to move and transfer.
· One-piece assembly structure, which can be powered on after disassembly and packaging.
Model
|
L-E70
|
L-E70-1
|
Max lifting height
|
1850mm
|
1850mm
|
Min platform height
|
820mm
|
820mm
|
Lifting capacity
|
1200kg
|
1200kg
|
Lifting platform length
|
1260mm
|
1260mm
|
Lifting platform width
|
660mm
|
660mm
|
X/Y direction translation distance of lifting platform
|
25mm
|
25mm
|
Voltage
|
DC12V
|
AC220V
|
Power
|
1.6Kw
|
0.75Kw
|
Lifting/Lowering time
|
40/30s
|
70/30s
|
Wheel diameter
|
4
|
4
|
Remote control power cord
|
3m
|
3m
|
