Inground car lift L4800A

Technical Parameters:

Lifting capacity：3500kg

Max. Lifting height：1850mm

Raising/Lowering Time: 40/60sec

Load sharing: max. 6:4 in or against drive-on direction

Supply voltage：AC380V50 Hz

Power：3 kW

The pressure of the air source：0.6-0.8MPa

Main unit length: 1700mm

Main unit width: 415mm

Main unit height：2514mm

Post Diameter：140mm

Post thickness：15mm

Sound level (measured at control console): ≤75 dBA

oil tank capacity ：12L

N.W.：1280kg
